1U 5-Zone Stereo Mixer 4 x 10 Channel all Balanced inputs/outputs
Item Code : Z5M
Special Notice: This Item is only sold when part of an installed Audio System.
Special Notice: This Item is only sold when part of an installed Audio System.
Product Details
Audio Mixers
adastra - 1U 5-Zone Stereo Mixer 4 x 10 Channel all Balanced inputs/outputs
Item Code: Z5M
Brand: adastra
Manufacturer: adastra
Description
Zoning Mixer
2 input, 5 zone mixer with individual volumes for both inputs and a mono switch for each zone.
All inputs and outputs are stereo via balanced XLR connectors.
Acts as the central mix and control in an installation serving up to 5 separate stereo speaker zones.
Features
- 2 inputs to 5 zones
- Mono selectable for each zone
- Fully balanced XLR connections
Images of Z5M
|
|
|
Specification
| Power supply | 115/230Vac 50/60Hz (IEC) | |
| Inputs Line | Line 1 L+R balanced XLRF. Line 2 L+R balanced XLRF | |
| Outputs | Zone 1 to 5 L+R balanced XLRM | |
| Input impedance | 40k Ohms | |
| Output impedance | 220 Ohms | |
| Frequency response | 20Hz - 25kHz, +0/-1dB | |
| Signal to noise ratio | >100dB | |
| THD | <0.005% | |
| Dimensions | 483 x 175 x 44mm | |
| Weight | 2.2kg |
